In this Electronza Blog post, Teodor Costachioiu describes how he tested out the capabilities of Microchip’s MPLAB® Mindi™ Analog Simulator using the MikroElektronika MCP16331.







Microchip SAMA5D27 SOM1 System-On-Module contains the 32-bit Arm® Cortex®-A5 processor-based MPU SAMA5D27 and 1Gb DDR2 SDRAM running up to 500MHz. It greatly simplifies design by integrating the power management, non-volatile boot memory, Ethernet PHY and high-speed lower power DDR2 memory onto a small, single-sided PCB. Certified for industrial operating conditions over a -40˚C to 85°C temperature range, application use includes motor control, HMI and other industrial applications.



The PA194 is a high voltage, high-speed power operational amplifier with extremely low noise. Low noise density in an electrical circuit is paramount for overall system performance, especially in applications that apply high voltages at very precise levels. The PA194 combines a low noise level of ~5 nV/√Hz @ 1 kHz with a very fast 1700 V/μs slew rate to enable fast rise times and fall times. Working with voltages of up to 900 V, this amplifier also provides 100 mA of continuous output current and a low 4 mA of quiescent current in standby mode thanks to an integrated standby mode for increased efficiency.
