New automotive-compliant power switch delivers adjustable current limit

By Michelle Froese

Diodes Incorporated introduces the new, AP22653Q programmable current-limiting power switch. Streamlining power- system design and assuring ongoing reliability, this automotive-compliant device provides a controlled and protected power path.

The new power switch is rated to handle continuous load currents of up to 1.5A. Key applications include protection of vehicle USB ports and ECU supply rails, as well as for infotainment and telematics subsystems.

With a tight accuracy margin of ±7% at high current levels, the AP22653Q’s current limit threshold can be simply set anywhere between 125 to 1735mA via use of standard value external resistors. The device’s controlled rise and fall times help to mitigate the effect of surges during turn on/off.

In addition, its 5μs short circuit response helps avoid situations requiring system shutdown or restart.

The AP22653Q has a 55mΩ (typical) on-resistance, which significantly reduces power loss and voltage drop at high load currents. The reverse-current protection integrated into this device safeguards against reverse currents when peripherals are being externally powered.

Over-temperature protection and under-voltage lockout features are also included. An operational temperature range of -40° to 125° C is supported.

The AP22653Q power switch is qualified to AEC-Q100 Grade 1, is manufactured in IATF 16949 certified facilities.
